20.1.8.40 innerShdw

This element specifies an inner shadow effect. A shadow is applied within the edges of the object according to the parameters given by the attributes.

Attributes

dist (Distance)

Specifies how far to offset the shadow.

The possible values for this attribute are defined by the ST_PositiveCoordinate simple type (20.1.10.41).

dir (Direction)

Specifies the direction to offset the shadow.

The possible values for this attribute are defined by the ST_PositiveFixedAngle simple type (20.1.10.44).

blurRad (Blur Radius)

Specifies the blur radius.

The possible values for this attribute are defined by the ST_PositiveCoordinate simple type (20.1.10.41).

[Note: The W3C XML Schema definition of this element’s content model (CT_InnerShadowEffect) is located in A.4.1. end note]
